ChemMax® 3

Advanced Chemical Protection for Industry, Emergency Response and Law Enforcement. ChemMAX® 3 is soft, flexible and tough with an extensive chemical barrier - use with Permasure® to instantly calculate Safe-Use Times

ChemMAX® is Lakeland's comprehensive range of coveralls for Type 3 & 4 protection against hazardous chemicals.

ChemMAX® 3 fabric features a UK-manufactured multi-layer barrier construction to provide protection against a wide range of hazardous chemicals. Co-extruded fabric technology means a smooth and flexible fabric that is free from the crushing and pitting suffered by adhesive or heat laminated barrier fabrics – so thickness, permeation and protection is uniform throughout the fabric surface.

Download Lakeland’s Guide to the Selection of Chemical Protective Clothing to assist in improved selection of the best suit for the job and for permeation and physical properties comparisons.

Supported by PermaSURE® :

Free, mobile-friendly online tool
Models permeation rates and provides safe-use times by incorporating environmental, temperature and chemical exposure factors.
State-of-the-art technology developed initially by leading Polymer chemists for defense forces to quickly determine which suits are needed for various chemical warfare agents and dual use chemicals.
Based on the known molecular characteristics and behavior of 4000+ chemicals interacting with ChemMax® 3.

ChemMax® 3 Brand Features

Multi-layer barrier film with smooth, flexible and even finish.
Permeation tested against a wide range of high hazard chemicals
Double zip / storm flap for secure protection to front fastening
Double layer cushioned knee-pads for comfort and security
All Lakeland chemical suits are available in a variety of styles including coveralls with attached socks, overboots and various partial body accessories

View All ChemMax® 3 Products

Resources

Documents
Sizing Charts
Page Links
Translations

Catalogs

ChemMax® 3 Documents

Ce Size Diagram 2018

Brand Details
Test Data

ChemMax® 3 Specifications

Seam Type: Stitched and taped
Materials: Multi-layer composite film including a high barrier film. 150 gsm.
Garment Configurations: All ChemMax coveralls are available as coveralls with elasticated hood, cuffs and ankles, with or without attached feet and various Partial Body accessories including jackets, pants, lab coats and overboots with anti-slip soles.
Colours: Grey, Orange
Packaging: Individually vacuum packed
Fabric Testing: Permeation tested against a wide range of chemicals

Applications

Chemical Handling
Petrochemical and Refining applications
Oil-spill clean-ups
Higher hazard chemical protection
Contaminated land clearing

Certifications

EN 14605 (Type 3 & 4)
EN 13982 (Type 5)
EN 13034 (Type 6)
EN 1149-5 (Anti-static)
EN 14126 (Bio hazard / infectious agents)
EN 1073 (radiation contaminated dusts)

ChemMax® 3 Physical Properties

Physical Property	Test Method	Units	Test Results
Abrasion Resistance	EN 530	Cycles	>2000 cycles / Class 6
Burst Strength	ISO 2960	Kilopascal	112.3kPa Class 2
Flex Cracking Resistance	ISO 7854	Cycles	150,000 flexes/ Class 4
Hydrostatic Head	ISO 811		-
Puncture Resistance	EN 863	Newtons	18.0N / Class 2
Resistance to Ignition	EN 13274-4		-
Seam Strength	EN 5082	Newtons	165.28N / Class 4
Tensile Strength - cd	ISO 13934	Newtons	110.0N / Class 2
Tensile Strength - md	ISO 13934	Newtons	170.0N / Class 3
Trapezoidal Tear - cd	EN 9073	Newtons	72.7N / Class 3
Trapezoidal Tear - md	EN 9073	Newtons	134.44N / Class 5
Trapezoidal Tear - mean	EN 9073	Newtons	103.57N / Class 5

Physical properties data is based on standard tests required by CE certification designed to allow easy comparison of the strength, durability and robustness of different garments. Lakeland's "Guide to Chemical Suit Selection" contains easy reference comparison tables of Lakeland garments with main competitors along with a glossary with brief explanation of the tests.

ChemMax® 3 Permeation Data

Challenge Chemical	CAS Number	Physical State	Normalized Breakthrough Time
Acetone	67-64-1		>480
Acetonitrile	75-05-8		>480
Carbon Disulphide			>480
Dichloromethane	75-09-2		>480
Diethylamine	109-89-7		Immediate
Ethyl Acetate	141-78-6		>480
Methanol	67-56-1		>480
n-Hexane	110-54-3		>480
Sodium Hydroxide			>480 (50%)
Sulphuric Acid (96%)			>480
Tetrahydrafuran			>480
Toluene	108-88-3	Liquid	>480
Nitrogen Dioxide	10102-44-0	Liquid	>480
Styrene	100-42-5	Liquid	>480
Dimethylethylamine	598-56-1	Liquid	137
Ethylbenzene	100-41-4	Liquid	>480
Monoethanolamine	141-43-5	Liquid	>480
Turco 5351	MIXTURE	Liquid	>480
Turco 6840	MIXTURE	Liquid	>480
Sodium Cyanide	143-33-9	Liquid	>480
Chloroform	67-66-3	GAS	>480
Cresol	95-48-7	Liquid	33
Epichlorohydrin	106-89-8	Liquid	176
PCB (Transformer Oil)	PCB	Liquid	>480

NOTE: Permeation test data relates to "Normalised Breakthrough" which measures the time for the permeation rate to reach a specific speed (In CE EN 6529 testing, 1.0µg/min/cm2 and in US ASTM F739 testing, 0.1µg/min/cm2). This does not indicate when the chemical first breaks through the fabric and is not an indication of how long the suit can be safely used as the chemical may have permeated through the fabric before the Normalised Breakthrough time. This might be critical in cases of chemicals with high toxicity.
